LEA

CS124

SMART AMP | 4 CHANNELS | 120 WATTS PER CHANNEL

Downloads

The CONNECTSERIES 124 is a 4-channel amplifier with 120 watts per channel in a ½ rack space form factor. As part of the Network CONNECTSERIES, the world’s first Internet of Things- (IoT) enabled professional-grade amplifiers, it is perfectly suited for small to medium-scale installations. The 124 features direct HiZ (70V or 100V) or LoZ selectable by channel. With three ways to connect, you can engage the built-in Wi-Fi access point, connect to the venue’s Wi-Fi, or use the FAST Ethernet to connect to any local area network via Cat5 or Cat6 cable.

Then there’s the Cloud…Network CONNECTSERIES is the first professional amplifier family to feature Cloud connectivity. Harness the power of the Cloud for remote control, monitoring, notifications, and more from any of your personal devices. Just connect your amp to a network and start commanding your systems.  Register for your free LEA Cloud account at leaprofessional.cloud

Specification

AUDIO SPECIFICATIONS

INPUTS

Analog: 4 Balanced Inputs with user selectable 26dB, 34dB, and mic level input sensitivity
4 unbalanced RCA inputs with user-selectable 26dB and 34dB input sensitivity
***Note - Unbalanced and RCA inputs share the same analog input channel

THD+N

0.1% (20Hz to 20kHz)

FREQUENCY RESPONSE

20Hz to 20kHz, +/- 0.5 dB @ 4Ω, 8Ω, 70V, 100V, -2.5dB @ 20kHz at 2Ω

SIGNAL TO NOISE LEVEL

102dB (20Hz to 20kHz referenced to 8Ω)

CROSSTALK

70dB (20Hz to 20kHz)

AMPLIFIER OUTPUT CLASSIFICATION

Class D with Proprietary Smart Power Bridge Technology allowing bridged output functionality without sacrificing an amplifier channel

DSP

DSP ARCHITECTURE

Analog Devices Sigma 96kHz DSP Processor with 32-bit Core with Sample Rate Converters

INPUT MATRIX

Routable matrix; any input to any output with primary and secondary input priority

CROSSOVERS

Up to 48 dB/Octave IIR Filters (Linkwitz Riley and Butterworth)

PARAMETRIC EQ

8 Band Parametric EQ per channel

OUTPUT DELAY

100ms per channel

OUTPUT PROTECTION

DC, VHF, and AC Mains Protection, Overtemp and Current Limiter, fan fault detection

USER ADJUSTABLE LIMITING

Peak Voltage and RMS Voltage

LOAD MONITORING

Realtime Load Monitoring and Pilot Tone Detection from Internal or External Sources

CONTROL, MONITORING, NETWORKING

USER INTERFACE

Web Browser User Interface, 3rd Party API control, Cloud control, or SharkWare

EXTERNAL I/O

External I/O In: Toggles Remote On/Off
External I/O Out: Indicates Amplifier Health
4 general Purpose input and output pins for general input
Triggering and output statuses - Coming Soon

OPERATION

AC MAINS

100VAC - 240VAC +/- 15% 50Hz or 60Hz

POWER SUPPLY

Universal Switch Mode Power Supply

PHYSICAL SPEC

DIMENSIONS (L X W X H)

Product: 11.82” x 8.58” x 1.71" (300.11mm x 218mm x 43.5mm)
Shipping: 18” x 11” x 2.75” (457.2mm x 300mm x 69.85mm)

WEIGHT

7lbs / 4.1kg | Shipping: Coming Soon

COOLING

Front to Rear Variable Fan Speed Cooling
Fan Noise at idle is 50dB @ 1m
Fan Noise at 50% is 57dB @1m
Fan Noise at full speed is 63dB @ 1m
